Pioneer SGY PM9100C Power Meter Component Kit

Comes with the power meter components, packaging for returning the consumer crank and a power meter installation Birth Certificate, which is used to detail the entire installation process.

• ⋅ Once purchased, the dealer completes the Birth Certificate and sends it with the consumer’s crankset (shipping box included) to Pioneer’s Central Installation Center, where it’s unboxed, disassembled, cleaned, and confirmed compatible for proper installation
• ⋅ The power meter is then installed, assembled, and calibrated; the entire process is estimated to last between 7-10 business days
• ⋅ Pioneer will keep in communication with the dealer during the entire installation process
• ⋅ Compatible with Shimano Dura-Ace 9000 or Ultegra 6800 cranksets ONLY
• ⋅ Compatible Crank-arm Lengths: 165, 167.5, 170, 172.5, 175, 177.5, 180mm
• ⋅ Compatible with ANT+ cycle computers for displaying power, cadence, and pedaling smoothness
• ⋅ Compatible with Garmin Left and Right Balance metric
• ⋅ Dual-Leg Power Meter: Dual Strain Gauges for Force Measurement and two accelerometers per arm for Force Direction Measurement
• ⋅ Extremely light, only adds 64g to the existing crankset
• ⋅ When used with Pioneer’s SGX-CA900 or SGX-CA500 Cycle Computer, the Force Vector Display shows force, force direction and where force is being applied for both right and left legs, in real-time
• ⋅ High accuracy thermal and voltage compensation, Accuracy +/- 2%
• ⋅ Up to 2150 Watt Measurement at 120RPM
• ⋅ Interchangeable Transmitter cover colors (red and black included)
• ⋅ Thin Left-Arm Sensor: 9mm
• ⋅ 180 Hour Battery life, with two user replaceable CR2032 batteries
• ⋅ Rotation Detection Magnets included, dual patch magnets and optional chain-stay adjustable magnets
• ⋅ Water Resistance Rating: IPX6 and IPX7
• ⋅ Two-Year parts and labor factory warranty

Includes Power Meter and shipping carton for Installation at Pioneer
